Inductive Load Bank

AC Load Bank

AC load bank main used to test the capability and aging degree for high-power ups on-line, inverter, switch power and diesel generator set for electric power, telecom department and manufacturer. It can ensure the reliability of constant power charge that adopts uniformly stepped power input, energy consumption work model and forced air-cooling model. It is of high power density, no red hot phenomenon and automatic protection function overheated. It can't be overheated and broken when the fans stop working. The complete machine can be operated simply and maintain convenient that adopts module design. It can test voltage and current according to client's request, and provide scientific test measures for high-power AC equipment.

Salient Feature:
1. Users can set adjustable discharge power according to capability parameter and test request.
2. Discharge time can be set: Load can be closed time out.
3. Voltage and current value can be displayed with digital meter.
4. The complete machine is of resistance breaking automatic overheated adopts new power consumption component.
5. AC load bank is of all kinds of specifications and series, and include resistance, inductive and capacitive load.
6. it’s of machine combination function.

Load bank is compact unit that are coupled to the output of your power generation system such as diesel generators, gas turbine or ups and battery system. The necessity and dependence on power at mining site, oil and gas refining in hospitals and many other essential services has meant a rapid growth of backup generators and ups system for backup power. The increase of computers and telecommunication equipment demands faultless performance in the event of power down conditions, this can only be full achieved by resistive load testing the stand by system on installation and at regular intervals.

Load banks are dummy loads designed to simulate the plant load and prove the design, performance and the capacity of the system without interruption to the normal running of your plant

Load bank are designed for portable resistive and reactive / inductive load bank one whether proof constriction, designed for harsh and tough environment is for testing and commissioning of generators featuring rugged stainless steel immersion proof and vibration proof resistors high quality class 'f' reactors integrated switch-gear with individual load circuit breakers.

Details:

• Data Centers
• Generator oem's & manufacture
• Commercial sectors
• Telecommunication Sites
• Mining
• Military Establishments
• Ships & Oil Rig Application
• Large Power Plants
• Battery Discharge Application

Inductive Load Bank

Inductive Load Bank is a high wattage inductive load network suitable for loading Single Phase and Three Phase motors, generators etc. equipment’s. The load banks are used to verify the performance of power sources, used to stimulate environment for testing power sources. Unique Design & Robust Construction contains three banks of inductive loads can be used with Single Phase and Three Phase Systems. Each bank of inductors is electrically isolated with separate terminals for each phase on panel through a star/delta switch. The user can switch easily between star and delta. Rotary Switches are provided to set the required load. The load is housed in powder coated MS fabricated structure with provision of castor wheels for easy movement in laboratories.





Electrical Load Bank

A load bank is a device which develops an electrical load, applies the load to an electrical power source and converts or dissipates the resultant power output of the source. The purpose of a load bank is to accurately mimic the operational or “real” load that a power source will see in actual application.

Features:

·         Excellent performance

·         Highly reliable

·         Easy to use & install

·         Feasible

·         Low maintenance

Applications:

·         HV power supplies

·         Medical instrumentation

·         Current pulse limiters

·         Ionization chambers



Industrial Resistive Load Banks are the most commonly used load banks for testing of generator sets and power systems. They can provide full KW loading to the power source to completely evaluate the engine cooling, exhaust and fuel systems. They will not load the generator to its full nameplate KVA capacity at 0.8 Power Factor. In order to load the generator to its full KVA rating, Inductive load banks will be required.

Salient Feature:

·         Develop the electrical loading, change or disperse the consequent power output of the source.

·         Included with load elements such as control as well as accessory devices needed for operation.

·         Give same loading for both prime movers and generators.

·         Load is made by the transmutation of electrical energy into heat through high-power resistors.

·         Re-create real-life resistive loadings, such as incandescent lighting and heating loads.

Applications:

·         Designed for the testing of switchgear, transformers, large generators and UPS systems.

·         Ideal for power plants, shipyards, OEMs and data centers.

·         Perfect for regular scheduled commissioning and maintenance testing of mission-critical secondary emergency power systems, where rated power factor, rated kVA and rated current testing is needed.

·         Factory experiment of engine diesel generator sets and turbines.

·         Battery and UPS system testing

·         Ground power testing

·         Optimization of load in prime power applications

·         Periodical exercising of stand-by engine generator sets

·         Data center tests (air-conditioning and electricity)

·         Load rejection tests
